2005 suzuki c50 with tramp conversion

[jack1576]

ok I found the grease fitting on the rear universal joint, where is the one on the dogbone, left or right side underneath, I can't see it



[Lee H. Mann]

ok I found the grease fitting on the rear universal joint, where is the one on the dogbone, left or right side underneath, I can't see it

The pivot point at the rear of the dogbone, beneath and right in the middle of that portion of the swingarm. Use a mirror and a flashlight or just feel around where the dogbone pivot pin passes through the swingarm.



[jack1576]

The pivot point at the rear of the dogbone, beneath and right in the middle of that portion of the swingarm. Use a mirror and a flashlight or just feel around where the dogbone pivot pin passes through the swingarm.

Thanks Jim I found it



[Lee H. Mann]
