Stallion Trike

[TomyJ]

Information wanted on engine/trans measurements LxWxH



[Gorilla]

Tomy,

Thoroughbred Motor Sports the maker of the Stallion purchased the drive trains straight from FORD. The drive trains were for a 2007 FORD Ranger Pick up truck. They came with a FORD warrantee on the drive train. FORD quit putting the 4 cylinder 2.3 motor in the ranger and the availability of the drive train dried up for TBMS. They had Rousch Racing re-program the ECU to work in the Stallion. I will try and get you the measurements later today. I expect you want over all size.



[TomyJ]

Stallion

Tomy,

Thoroughbred Motor Sports the maker of the Stallion purchased the drive trains straight from FORD. The drive trains were for a 2007 FORD Ranger Pick up truck. They came with a FORD warrantee on the drive train. FORD quit putting the 4 cylinder 2.3 motor in the ranger and the availability of the drive train dried up for TBMS. They had Rousch Racing re-program the ECU to work in the Stallion. I will try and get you the measurements later today. I expect you want over all size.

YES, I would like the over all sizes and Thank You.



[Gorilla]

here is what I approx measured. width of motor is appox 26 wide with a/c compressor, or about 20 inches wide without the compressor.

about 57 inches long from front pulley to rear of transmission with front u-joint

30 inches high from bottom of oil pan to top of engine.

tail of transmission 10 inch off ground top of tail 14 inches

best I could do hope this helps. hard to get measurements when it,s in the vehicle



[TomyJ]

Thank you Ted

here is what I approx measured. width of motor is appox 26 wide with a/c compressor, or about 20 inches wide without the compressor.

about 57 inches long from front pulley to rear of transmission with front u-joint

30 inches high from bottom of oil pan to top of engine.

tail of transmission 10 inch off ground top of tail 14 inches

best I could do hope this helps. hard to get measurements when it,s in the vehicle



[John Luciano]

I have not seen one in years. I go to Americade ( 35,000 people ) 18,000 motorcycles. Only have seen 6 in 10 years and 3 were dealers. They still sell them? I did drive one and loved the feeling after I got use to gas with one foot brake with the other. WEIRD at first



[2006gold]

No longer manufactured. My understanding is the last units were produced in 2013, and then only 50. Another thread on this site states there were only 930 manufactured. I live in DFW and know of only four in this area, including mine. Explore the 'net and you could find one for sale somewhere.



[Buddy13]

For sale

anybody know of one for sale?



[tomg]

anybody know of one for sale?

Yes but it is in central Florida! Tomg
